Stainless Steel Sheet: Properties, Advantages, and Processing
Dinglian Co., supply Stainless Steel Sheet, a versatile and corrosion-resistant material prized for its strength and aesthetic appeal. This sheet metal, an alloy containing chromium, finds widespread use in kitchenware, construction, medical equipment, and automotive parts. Classifications are primarily based on the American Iron and Steel Institute (AISI) numbering system, such as 304 (general purpose) and 316 (enhanced corrosion resistance), each tailored for specific applications.
Specifications
- Common Thickness Range: Typical thickness spans from a thin 24 gauge (around 0.024 inches or 0.6 mm) up to a substantial 7 gauge (approximately 0.1875 inches or 4.8 mm).
- Standard Width Options: Common widths include 36 inches (914 mm), 48 inches (1219 mm), and 60 inches (1524 mm), catering to diverse project needs.
- Typical Length Selections: Standard lengths frequently offered are 96 inches (2438 mm) and 120 inches (3048 mm), providing ample material for many applications.
- Common Grade Varieties: Popular grades encompass 304 (general use), 316 (corrosion resistant), and 430 (ferritic, good formability), among others.
- Standard Surface Finishes: Finishes like 2B (smooth, mill finish), #4 (brushed), and BA (bright annealed) are commonly available, influencing appearance.
- Density Average Value: The density generally hovers around 0.28 lbs/cubic inch (7.85 g/cm³), impacting the weight considerations for projects.
- Yield Strength Range: Yield strength typically ranges from 30 to 50 ksi (205 to 345 MPa) depending on the specific grade and temper.
- Tensile Strength Spectrum: Tensile strength usually falls within the 70 to 100 ksi (485 to 690 MPa) range, indicating the material's breaking point.
- Elongation Percentage: Elongation, a measure of ductility, commonly ranges from 40% to 60% in standard stainless steel sheets.
- Customizable Dimensions: Beyond standard sizes, many suppliers offer custom cutting to specific length and width requirements for tailored applications.
